Pressure relief valves
-Pressures to 60,000 PSI
-Stainless Steel Construction
-Wide Pressure Adjustment Range
-Manual Adjust or Air Dome Controlled
-Large Orifice for High Flow Applications
-Retains Pressure Setting Regardless of Seat Wear
| Max Pressure |
Style |
Port Size |
Port Type |
| 30 |
RVA |
09 |
MPF |
| |
|
|
|
20=20,000 PSI
|
|
04=1/4" |
MPF=Medium Pressure Female |
| |
|
06=3/8" |
|
| |
|
09=9/16" |
MPM=Medium Pressure Male
Nipple Only |
30=30,000 PSI
|
|
12=3/4" |
|
| |
|
16=1" |
HPF=High Pressure Female |
60=60,000 PSI
|
|
|
HPM=High Pressure Male
Nipple Only |
| |
|
|
M=Type M Male |
| Seal Option |
| Blank=Std. urethane |
The Air Dome Controlled version is ideal for remote adjustments of system pressure. The air dome can be controlled by an electro/pneumatic device to create pressure profiles for test and manufacturing applications. | |
